Forklift Throttle Body
Forklift Throttle Body - Where fuel injected engines are concerned, the throttle body is the component of the air intake system which controls the amount of air which flows into the engine. This mechanism functions in response to driver accelerator pedal input in the main. Generally, the throttle body is placed between the intake manifold and the air filter box. It is often attached to or positioned near the mass airflow sensor. The biggest piece within the throttle body is a butterfly valve known as the throttle plate. The throttle plate's main function is so as to control air flow.
On most cars, the accelerator pedal motion is transferred through the throttle cable, therefore activating the throttle linkages works so as to move the throttle plate. In cars consisting of electronic throttle control, otherwise referred to as "drive-by-wire" an electric motor regulates the throttle linkages. The accelerator pedal connects to a sensor and not to the throttle body. This particular sensor sends the pedal position to the ECU or otherwise known as Engine Control Unit. The ECU is responsible for determining the throttle opening based upon accelerator pedal position along with inputs from various engine sensors. The throttle body consists of a throttle position sensor. The throttle cable is attached to the black part on the left hand side that is curved in design. The copper coil located close to this is what returns the throttle body to its idle position as soon as the pedal is released.
The throttle plate revolves inside the throttle body every time the operator applies pressure on the accelerator pedal. This opens the throttle passage and enables more air to flow into the intake manifold. Usually, an airflow sensor measures this change and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors to be able to produce the desired air-fuel ratio. Frequently a throttle position sensor or also called TPS is connected to the shaft of the throttle plate to provide the ECU with information on whether the throttle is in the wide-open throttle or "WOT" position, the idle position or anywhere in between these two extremes.
In order to control the minimum air flow while idling, some throttle bodies could have valves and adjustments. Even in units that are not "drive-by-wire" there would normally be a small electric motor driven valve, the Idle Air Control Valve or likewise called IACV which the ECU uses so as to regulate the amount of air which could bypass the main throttle opening.
In several cars it is common for them to contain a single throttle body. In order to improve throttle response, more than one could be used and connected together by linkages. High performance cars like the BMW M1, along with high performance motorcycles such as the Suzuki Hayabusa have a separate throttle body for each and every cylinder. These models are called ITBs or also known as "individual throttle bodies."
A throttle body is similar to the carburetor in a non-injected engine. Carburetors combine the functionality of the throttle body and the fuel injectors into one. They function by blending the air and fuel together and by modulating the amount of air flow. Vehicles which include throttle body injection, that is known as TBI by GM and CFI by Ford, put the fuel injectors within the throttle body. This enables an older engine the opportunity to be converted from carburetor to fuel injection without really altering the design of the engine.
